Hydraulic Roller Stacker
HYDRAULIC ROLLER STACKER
MKP 121
Cap: 500/1000/1500 kgs
Max ht:1600 mm
Max ht:1600 mm
Structure : Simplex Design Single Mast Structure Made From ‘C’ Channel Section, Supported By Heavy-Duty Deep Grooved Guide Rollers. Forks Lifted By Means Of 2 Nos. Simplex Chain & Pulley Design.
Hydraulic Unit : 1 No. Vertical Mounted,Single Acting,Honned Hyd. Cylinder With Hard-Chrome Plated Piston Which Is Actuated By 1 No. Hydraulic Single Acting Hand Pump.
Wheels : 2 Nos. 200 x 50 mm. Size White Virgin Nylon Wheels At Front (Handle) Side & 4 Nos. 150 X 50 mm. Size Load Roller Wheels At Rear Side. All Wheel Contains Double Ball Bearings For Easy Movement Of Stacker.
Handle : Inverted ‘U’ Shape Handle For Push-Pull Action Of Stacker.
Paint : One Coat Of Primer & Two Coats Of Auto-Finish Paint.
Specifications
| Product Code | MKP-121 | |
| Rated Capacity | tons | 0.5 / 1 / 1.5 |
| Load center | mm | 350 |
| Min. Fork Height | mm | 110 |
| Max. Fork Height | mm | 1600 / 3000 |
| Platform Length | mm | 700 / 900 |
| Platform Width | mm | 600 / 700 |
| Min. Turning Radius | mm | 1500 |
| Wheelbase | mm | 850 |
| Front Wheel Distance | mm | 250 |
| Overall Length | mm | 1150 |
| Overall Width | mm | 800 |
| Overall Height | mm | As Per Height |
| Self Weight | kg | 400 |
