DOUBLE CYLINDER TROLLEY

Size : 30” L X 18” W X 12” H.

Structure : Will Be Made From 75 X 40 Mm. M.S. ‘C’ Channel With 35x35x5 Mm. M.S. Angle, 30x 5 Mm. M.S. Flat, 1” Dia. M.S. Pipe & 16 Swg M.S. Sheet.

Wheels : 3 Nos. 8” X 2” Size H.D.P.E. Wheels With 2 Nos. 6205 ‘Z’ Type Double Ball Bearings In Each Wheel. 1 No. Swivell Castor At Front Side & 2 Nos. Fixed Mounted Castor At Rear Side.

Handle : 1 No. ¾” Dia. M.S. Pipe Handle For Push-Pull Purpose.

Paint : One Coat Of Primer & Two Coats Of Syn. Enamel Paint.
